Response Time : Max. 1 ms

Material : Case: Polycarbonate, Lens, Lens cover: Polymethyl Methacrylate Acrylic

Type of Product : Photoelectric Sensors

Weight : Approx. 120 g (approx. 50 g)

Protection Structure : IP67

Light Source : Red LED (660 nm)

Sensing Target : Opaque material of min. Ø75mm

Sensing Type : Retroreflective Type with Built-In Polarizing Filter

Operation Mode : Selectable Light On Or Dark On By Control Wire (White)

Current Consumption : Max. 30 mA

Sensitivity Adjuster : Sensitivity adjuster

Ambient Illumination : Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination)

Environment Ambient Humidity : 35 to 85% RH, storage: 35 to 85% RH

Environment Ambient Temperature : -25 to 60℃, storage: -30 to 70℃
