Features |
|
Brand Name : | STEEL-SMITH |
Port size : | G-3/8 |
Model No : | AOT-HV-2400-H-TM-TU |
Cylinder Bore : | 63 mm |
Type of Product : | Pneumatic Clamps |
Clamp Arm Opening : | 105° |
More Details |
-
Warranty
As per STEEL-SMITH's policy -
100% Original
Products -
Free Shipping
on orders above Rs. 1,000 -
Secure
Payments -
100% buyer
Protection -
EARN
IB Coins -
7 days
Returnable
The STEEL-SMITH Pneumatic Clamps 23.50kN AOT-HV-2400-H-TM-TU is the solution to applications, which demands Precision, Performance and the most important factor as far as fixturing is concerned Compactness. These clamps have been specially designed by gathering information and suggestions from customers presently using Steel-Smith pneumatic clamps. The design helps a fixture manufacturer
as far as space constrains is concerned. These clamps are flexible from the maintenance point of view, with features like compatible to all standards, brands and types of pneumatic cylinders. The linkages, connector to piston rod, and the clamping device consists hardened bushings and pivot pins which are easily replaceable in case of wear outs. The clamping device comes with mounting holes, which can be according to the customer's requirement helping them to standardize on their clamping adaptors. The mounting of the clamp can also be customized in case of substitutes. This pneumatic clamps are available in cylinder size from 16mm bore to 63mm bore size. These clamps are the air powered version of the manual Series. They comprise of a very strong and rugged toggle mechanism actuated by a double acting cylinder. The clamping arm is provided with the clamp and can be welded at any desired angle to suit the individual requirement of work pieces. These clamps carry the over Centre Toggle Lock principle for maximum safety as they remain in locked condition even in case of air failure. The clamps have almost all the features of the manual clamps. These clamps are available in three sizes off the shelf.
Pneumatic Clamps Installation Guide
Steel-Smith supplies all Pneumatic Clamps with magnetic cylinders, a standard reed switch can be mounted on these cylinders for sensing.
It is highly recommended that all the Pneumatic Clamps are used with flow control valve on both ports of the Cylinders. This ensure that the clamping arm clamps the component at a regulated speed.
Buy STEEL-SMITH Pneumatic Clamps 23.50kN AOT-HV-2400-H-TM-TU online in India at wholesale rates. If you have been looking for STEEL-SMITH Pneumatic Clamps 23.50kN AOT-HV-2400-H-TM-TU dealers, your search ends here as you can get the best STEEL-SMITH Pneumatic Clamps 23.50kN AOT-HV-2400-H-TM-TU distributors in top cities such as Delhi NCR, Mumbai, Chennai, Bengaluru, Kolkata, Chennai, Pune, Jaipur, Hyderabad and Ahmedabad. You can purchase STEEL-SMITH Pneumatic Clamps 23.50kN AOT-HV-2400-H-TM-TU of the finest quality and rest assured to get the best in terms of both durability and performance. If you are bothered about the STEEL-SMITH Pneumatic Clamps 23.50kN AOT-HV-2400-H-TM-TU prices, you can be totally sure to get the best rates as Industrybuying brings you genuine STEEL-SMITH Pneumatic Clamps 23.50kN AOT-HV-2400-H-TM-TU rates and quality assured products only from the best of brands with exclusive brand discounts you won’t find anywhere else. Procure STEEL-SMITH Pneumatic Clamps 23.50kN AOT-HV-2400-H-TM-TU today and avail the best offers on your purchase.
18,332
(GST inclusive price)
15,536
(GST extra)
|
